J - Ring Appratus Manufacturer,Supplier and Exporter in India
Product Code : TVT-CTE-10507
The J-Ring Apparatus determines the passing ability of self-compacting concrete (SCC) as it flows through the tight openings and spaces between reinforcing bars, without segregation or blocking.
How It Works
The J-Ring — a steel ring fitted with vertical bars spaced at set intervals — is placed around the slump cone on a level base. As the concrete flows out through the bars after the cone is lifted, the spread diameter and the flow time to reach 500mm (T500) are recorded, together with the difference in concrete height inside versus outside the ring, indicating how well the mix passes through congested reinforcement.
Technical Specifications
| Parameter | Specification |
|---|---|
| Test Measured Parameter | T500 flow time to 500mm diameter spread |
Applications
Used to assess the passing ability of self-compacting concrete through reinforcement per EN 12350-12 (J-Ring test), typically alongside slump-flow and V-Funnel/L-Box tests when qualifying an SCC mix design.
Related Products & Category
This machine is part of the Concrete Testing Equipments range at Tvet Equipments. Related machines include: L-Box, V-Funnel.
Frequently Asked Questions
What does the J-Ring test measure?
It measures the passing ability of self-compacting concrete — how well the mix flows through the gaps between reinforcing bars without segregating or blocking, alongside the T500 flow time.
How is the J-Ring test typically combined with other SCC tests?
It is commonly used together with the slump-flow test, the L-Box passing-ability test, and the V-Funnel filling-ability test to fully characterise an SCC mix.
What does a large height difference across the ring indicate?
A larger difference between the concrete height inside and outside the ring generally indicates poorer passing ability, often due to blocking at the reinforcement bars.
