Full Auto Comp cw Controls Automax E-Modulus Manufacturer,Supplier and Exporter in India
Product Code : TVT-CTE-10443
The Full Auto Comp cw Controls Automax E-Modulus is a fully automatic 2000 kN compression machine fitted with the "Automax E-Modulus" power-control system, built specifically to determine the static modulus of elasticity and Poisson's ratio of concrete cylinders under compression, in addition to standard compressive strength testing.
How It Works
The oversized 4-column high-stability frame and precision-lapped upper and lower platens keep the specimen concentrically and evenly loaded, which is essential for modulus-of-elasticity testing since eccentric loading distorts the strain readings. The Automax control system applies load through repeatable, programmed cycles rather than a single ramp to failure, which is the basis of the static modulus test procedure. To capture longitudinal and lateral strain during those load cycles, this type of test is run together with a compressometer-extensometer assembly — buyers should confirm with Tvet Equipments whether a compressometer-extensometer is bundled with this machine or needs to be ordered separately, as it is not listed as a line item on the published spec sheet. The same frame, run in a single ramp to failure without the modulus cycling, also functions as a standard 2000 kN compression testing machine.
Technical Specifications
| Parameter | Specification |
|---|---|
| Maximum Capacity | 2000 kN |
| Main Frame | High-stability 4-column frame |
| Frame Max. Vertical Clearance | 335 mm |
| Frame Max. Horizontal Clearance | 275 mm |
| Upper & Lower Platen Diameter | 216 mm |
| Piston Ram Diameter | 250 mm |
| Piston Ram Travel | 80 mm |
| Frame Dimension | 360 x 950 x 1300 mm |
| P.C.S. Dimension | 500 x 650 x 1354 mm |
| Approx. Total Weight | 700 kg |
| Power Supply | 220V, 1 Ph, 50/60 Hz, 720W |
Applications
This machine's primary application is determining the static modulus of elasticity and Poisson's ratio of concrete in compression per ASTM C469 and EN 12390-13, a key input for structural design and for concrete mix qualification on major infrastructure projects. Run as a standard compression tester, the same 2000 kN frame is also used for compressive strength testing of concrete cubes and cylinders per ASTM C39, IS 516, and EN 12390-4.
Related Products & Category
This machine is part of the Concrete Testing Equipments range at Tvet Equipments. Related machines include: Welded Frame Compression Machine 3000kN, Automatic Compression Machine (Welded Frame) 5000kN.
Frequently Asked Questions
What test is the Automax E-Modulus system designed for?
It is designed to determine the static modulus of elasticity and Poisson’s ratio of concrete cylinders under compression, per ASTM C469 and EN 12390-13.
Does it also perform standard compressive strength testing?
Yes — run as a single ramp-to-failure test, the 2000 kN frame functions as a standard compression testing machine per ASTM C39, IS 516, and EN 12390-4.
Is a compressometer-extensometer included with the machine?
This is not listed on the published spec sheet — confirm with Tvet Equipments whether the strain-measurement assembly needed for the modulus test is bundled or supplied as a separate accessory.
