Welded Frame Compression Machine 3000kN Manufacturer,Supplier and Exporter in India
Product Code : TVT-CTE-10440
The Welded Frame Compression Machine 3000kN is a high-capacity, fully welded-frame concrete compression testing machine built for laboratories that routinely test high-strength cubes, cylinders and blocks. It runs on Tvet Equipments' Super Test 9.1 control software with dual test programs for compression and flexural testing, selectable sample-size routines for cubes, blocks and cylinders, and automatic reporting of up to 10 samples in a single test report.
How It Works
A specimen is centred on the lower compression platen and the upper platen is brought down to make contact. The hydraulic power pack applies load through the piston ram at an operator-set or programmed loading rate, while a digital load sensor (0.1% sensor accuracy) continuously reports the applied force to the Super Test 9.1 console. The system logs peak load, computes compressive strength from the specimen's bearing area, and stores the result in the batch report. Because the frame is a single welded (non-tie-rod) structure rather than a bolted assembly, it offers high rigidity for repeated high-load cycles. When fitted with a flexural bend-test jig (supplied as an accessory), the same load frame and software can additionally run flexural strength tests; buyers who need on-day flexural capability should confirm the jig is included in their configuration.
Technical Specifications
| Parameter | Specification |
|---|---|
| Max. Vertical Clearance | 350 mm |
| Max. Horizontal Clearance | 290 mm |
| Capacity | 3000 kN x 1.0 kN Sensitivity |
| Compression Platen Diameter | 300 mm |
| Piston Ram Diameter | 300 mm |
| Piston Ram Travel / Column Diameter | 80 mm |
| Accuracy Class | Class 1 |
| Loading Rate Range | 1 kN/s |
| Relative Error | ±1% |
| Repeatability Relative Error | 1% |
| Zero Drift | ±0.1% |
| Resolution | 0.5% |
| Sensor Accuracy | 0.1% |
| Max. Hydraulic Working Pressure | 25 MPa |
| Product Dimension | 960 x 500 x 1200 mm |
| Packing Dimension | 1060 x 600 x 1450 mm |
| Approx. Product Weight | 900 kg |
| Approx. Packing Weight | 1000 kg |
| Power | 0.75 kW |
Applications
This machine is used for compressive strength testing of concrete cubes and cylinders under ASTM C39, IS 516 (Part 5), and EN 12390-4, covering routine acceptance testing of high-strength structural concrete. With the optional flexural bend-test jig fitted, the same frame and software support third-point and centre-point flexural strength testing of concrete beams per ASTM C78 / C293, IS 516, and EN 12390-5.
Related Products & Category
This machine is part of the Concrete Testing Equipments range at Tvet Equipments. Related machines include: Touch Screen Welded Frame Compression Machine 2000kN, Automatic Compression Machine (Welded Frame) 5000kN.
Frequently Asked Questions
What size specimens can this machine test?
The 300 mm compression platen accommodates standard 150 mm cubes and 150 mm dia. cylinders as specified in IS 516 and ASTM C39, as well as larger blocks within the platen area.
Does it test flexural strength as well as compression?
The Super Test 9.1 software includes a flexural test program; running flexural tests requires fitting the flexural bend-test jig accessory to the frame — confirm inclusion with Tvet Equipments at the time of order.
What accuracy class does the machine meet?
The load-measuring system is rated Class 1, with a relative error and repeatability of ±1%, consistent with the accuracy requirements referenced in ASTM C39 and EN 12390-4 for compression testing machines.
