Touch Screen Welded Frame Compression Machine 2000kN Manufacturer,Supplier and Exporter in India
Product Code : TVT-CTE-10441
The Touch Screen Welded Frame Compression Machine 2000kN pairs a high-tensile carbon-steel welded frame with an imported DC motor drive and a touch-screen control console, giving laboratories a 2000 kN concrete compression machine with dual channels for compression and flexural test programs.
How It Works
The DC motor drives the hydraulic pump smoothly, reducing noise and vibration compared with conventional AC-motor pumps, while giving finer control over the loading rate. The touch-screen console selects between the compression and flexural test channels, guides the operator through specimen setup, and logs the peak load and computed strength automatically. The welded (as opposed to tie-rod) frame construction, with a 32 mm column thickness, is designed to resist deflection under repeated high-load testing cycles, helping keep readings consistent over the working life of the machine.
Technical Specifications
| Parameter | Specification |
|---|---|
| Max. Vertical Clearance | 340 mm |
| Max. Horizontal Clearance | 340 mm |
| Capacity | 2000 kN x 1.0 kN Sensitivity |
| Compression Platen Diameter | 295 mm |
| Piston Ram Diameter | 310 mm |
| Piston Ram Travel | 80 mm |
| Column Thickness | 32 mm |
| Accuracy Class | Class 1 |
| Product Dimension | 960 x 500 x 1200 mm |
| Packing Dimension | 1060 x 600 x 1400 mm |
| Approx. Product Weight | 950 kg |
| Approx. Packing Weight | 1000 kg |
| Power | 220V, 2.5 Amp, 50/60 Hz, 0.75 kW, 1 Ph |
Applications
Used for compressive strength testing of concrete cubes and cylinders under ASTM C39, IS 516, and EN 12390-4. The flexural test channel, used together with a flexural bend-test jig, supports third-point and centre-point flexural testing of concrete beams per ASTM C78 / C293, IS 516, and EN 12390-5.
Related Products & Category
This machine is part of the Concrete Testing Equipments range at Tvet Equipments. Related machines include: Welded Frame Compression Machine 3000kN, Automatic Compression Machine (Welded Frame) 5000kN.
Frequently Asked Questions
How does this machine differ from the 3000kN welded frame model?
This model is rated to 2000 kN with a 295 mm platen and touch-screen control, compared with the higher 3000 kN capacity and 300 mm platen of the welded frame 3000kN machine — choose based on the maximum specimen strength expected.
What powers the machine?
It runs on a single-phase 220V supply at 2.5 Amp, 50/60 Hz, drawing 0.75 kW through the imported DC motor drive.
Is the frame construction different from bolted/tie-rod compression machines?
Yes — this is a fully welded high-tensile carbon-steel frame with a 32 mm column thickness, built for rigidity under repeated high-load compression cycles.
