Portable Flexural Test Device Manufacturer,Supplier and Exporter in India
Product Code : TVT-CTE-10436
The Portable Flexural Test Device from Tvet Equipments is an economical, simple three-point flexural test jig with a single upper roller that fits any type of compression machine, letting laboratories add concrete beam flexural testing to existing equipment.
How It Works
A concrete beam specimen is supported on two lower bearers within the device's frame, and the compression machine's ram applies load through the device's single upper roller at the beam's mid-span, in a center-point (three-point) loading configuration. The device accommodates two common beam specimen sizes, giving laboratories flexibility for different maximum aggregate sizes.
Technical Specifications
| Parameter | Specification |
|---|---|
| Dimension (L x W x H) | 600 x 220 x 420 mm |
| Test Specimen Size | 100 x 100 x 400/500 mm or 150 x 150 x 600/750 mm |
| Approx. Weight | 39 kg |
Applications
This device is used to carry out center-point loading flexural strength tests on concrete beams to ASTM C293 / IS 516 / EN 12390-5, its economical single-roller design letting laboratories fit flexural testing capability to any compatible compression machine rather than needing a dedicated flexural testing machine.
Related Products & Category
Part of Tvet Equipments' Concrete Testing Equipments range, complementing the Digimatic Compression Machine 2000kN.
Frequently Asked Questions
Q1. What standard governs this flexural test method?
ASTM C293, IS 516 and EN 12390-5 specify center-point loading flexural strength testing of concrete beams, the single-upper-roller method this device provides.
Q2. What beam sizes can this device test?
It accommodates 100 x 100 x 400/500 mm and 150 x 150 x 600/750 mm beam specimens, covering common maximum-aggregate-size requirements.
Q3. Can it be used with any compression machine?
Yes, it is designed as a simple, economical device that can be fitted to any type of compression machine to add flexural testing capability.
