Digimatic Compression Machine 2000kN Manufacturer,Supplier and Exporter in India
Product Code : TVT-CTE-10431
The Digimatic Compression Machine 2000kN from Tvet Equipments is an extremely strong, oversized compression testing machine built for high rigidity and stability, featuring a ball-seated upper platen and a base platen with a 150 mm cube centering guide pin for accurate concrete cube testing.
How It Works
A concrete cube specimen is centred on the base platen's guide pin and loaded via the fixed upper head's ball-seated platen, ensuring even load distribution even with minor specimen face irregularities. The rapid-approach system closes the gap to the specimen quickly before controlled loading at Grade 1.0 compression accuracy, while a piston anti-over-travel limit switch and full front-and-side safety enclosure protect the operator. The digimatic multi-function controller displays force in kN and MPa, holds maximum force with a real-time force-versus-time graph, runs multiple test programs, auto-saves up to 450 results, and outputs via RS-232 for instant printing.
Technical Specifications
| Parameter | Specification |
|---|---|
| Capacity | 2000 kN |
| Low Range Sensitivity | 0-999 x 0.1 kN |
| High Range Sensitivity | 1000-2000 x 1 kN |
| Max. Vertical Clearance | 400 mm |
| Max. Horizontal Clearance | 285 mm |
| Compression Platen Diameter | 216 mm |
| Piston Ram Diameter | 250 mm |
| Piston Ram Travel | 50 mm |
| Column Diameter | 65 mm |
| Product Dimension (L x W x H) | 360 x 950 x 1330 mm |
| Approx. Product Weight | 625 kg |
| Power | AC 220 V, 1 ph, 4.9 A, 50/60 Hz |
Applications
This machine is used for compressive strength testing of 150 mm concrete cubes to ASTM C39 / IS 516 / EN 12390-4, its built-in centering guide pin and ball-seated platen designed specifically to ensure accurate, repeatable cube compression results.
Related Products & Category
Part of Tvet Equipments' Concrete Testing Equipments range, an alternative capacity to the Touch Screen Compression Machine 3000kN.
Frequently Asked Questions
Q1. What cube size is this machine designed for?
It is built with a 150 mm cube centering guide pin on the base platen, designed specifically for standard 150 mm concrete cube compression testing.
Q2. What standard governs this test?
ASTM C39, IS 516 and EN 12390-4 all specify compressive strength testing of concrete cube specimens.
Q3. What safety features does the machine include?
A piston anti-over-travel limit switch and full front-and-side safety enclosure protect the operator during testing.
