Product Code : TVT-BATE-10377
The Binder Analyzer (Ignition Method) from Tvet Equipments is an advanced, touchscreen-controlled ignition oven for determining asphalt binder content and aggregate gradation of Hot-Mix Asphalt, with programmable combustion profiles for different mix types and extensive on-board data logging.
How It Works
A weighed HMA sample is placed in the combustion chamber, and the operator selects or creates a combustion program (up to 30 can be stored) specifying combustion temperature, aggregate correction factor, and burn time to suit the specific mix being tested. As the furnace burns off the binder, an internally calibrated balance continuously tracks mass loss, and the large colour touchscreen displays a real-time loss curve and temperature curve. Once the sample weight stabilises, the analyzer calculates binder content automatically, storing the full test record — results, protocol, and graphs — for later review or printing; up to 100 test groups can be retained in memory.
Technical Specifications
| Parameter | Specification |
|---|---|
| Balance Range | 10.0 kg, 0.1 g resolution |
| Max. Combustion Chamber Setpoint | 600 °C (chamber temperature-resistant to 1200 °C) |
| Temperature Measurement Range | 0-1024 °C, 0.5 °C resolution |
| Maximum Sample Mass | 3500 g (recommended 1200-1800 g) |
| Test Stability Factor | 0.1% |
| Stored Combustion Programs | Up to 30 |
| Stored Test Groups | Up to 100 |
| Relative Humidity (Operating) | ≤ 85% |
| Ambient Temperature (Max) | ≤ 35 °C |
| Heating Power | 9 kW, three-phase four-wire Y connection |
| Power Supply | Three-phase four-wire AC415V ±10% |
| Combustion Chamber Dimensions | 320 x 450 x 280 mm |
| Overall Dimensions | 790 x 735 x 1640 mm |
| Instrument Weight | 220 kg |
Applications
The Binder Analyzer (Ignition Method) is used for determining asphalt binder content by the ignition method under ASTM D6307 / AASHTO T308, with its higher maximum sample mass, wider temperature range, and program storage suiting high-throughput asphalt plant QC laboratories and highway agency material approval facilities.
Related Products & Category
Part of Tvet Equipments' Bitumen Asphalt Testing Equipment range, a higher-capacity, touchscreen-controlled counterpart to the Asphalt Binder Analyzer (Ignition Method).
Frequently Asked Questions
Q1. How many combustion programs can be stored?
Up to 30 independent combustion programs can be stored, each with its own temperature, aggregate correction factor, and timing settings for different mix types.
Q2. Can the balance be calibrated without removal?
Yes, the unit supports internal calibration of the balance without removing it from the instrument, simplifying routine maintenance.
Q3. How much test data can it store?
It can store up to 100 groups of test data, including full results, protocols, and graphs, which can be viewed or printed at any time from the touchscreen interface.
