Manual Marshall Compactor Manufacturer,Supplier and Exporter in India

Manual Marshall Compactor

Product Code : TVT-BATE-10336

The Manual Marshall Compactor from Tvet Equipments compacts Marshall specimens by hand for asphalt mix sample preparation.

How It Works

The operator raises and drops a 4.535 kg hammer through a fixed 457 mm free-fall height onto the specimen mould, repeating the compaction blows on each face as specified by the Marshall mix-design procedure.

Technical Specifications

ParameterSpecification
Dimension370(L) x 300(W) x 2000(H) mm
Height of Hammer Drop457 mm
Weight of Hammer4.535 kg
Approx. Weight66 kg

Applications

Manual Marshall compaction follows ASTM D6926, used for preparing asphalt mix-design specimens where an automatic compactor is not required or available.

Related Products & Category

Part of Tvet Equipments' Bitumen Asphalt Testing Equipment range, an economical alternative to the Automatic Marshall Compactor.

Frequently Asked Questions

Q1. What is the hammer drop height?
457 mm, with a 4.535 kg hammer.

Q2. Which standard governs Marshall compaction?
ASTM D6926.

Q3. When would a lab choose manual over automatic compaction?
For lower testing volumes or budget-conscious labs, or where an automatic compactor is not available.
