Universal Loading Frame Manufacturer,Supplier and Exporter in India
Product Code : TVT-STE-10570
The Universal Loading Frame is a low-capacity, microprocessor-controlled loading system designed as an accessory for uniaxial and unconfined compression tests, including triaxial and unconfined compressive strength testing on soil specimens.
How It Works
A stepper motor drives the loading platen at a precisely controlled, selectable speed while a microprocessor-based control unit with a keypad and large LED display manages the test sequence and displays load/deformation data in real time. The low-capacity design suits the relatively small loads involved in triaxial, unconfined compression and similar soil-strength tests, giving accurate, repeatable strain rates across a wide speed range.
Technical Specifications
| Parameter | Specification |
|---|---|
| Capacity | 10 kN |
| Speed Range | 0.0001 mm/min – 4.8 mm/min |
| Platen Travel | 100 mm |
| Control | Microprocessor-based, keypad control, large LED display, stepper-motor speed control |
| Dimension | 310 (L) x 380 (W) x 1100 (H) mm |
| Approx. Weight | 85 kg |
| Power Supply | 220–240 V, 50/60 Hz, single phase |
Applications
The Universal Loading Frame is used to perform unconfined compression tests per ASTM D2166 / IS 2720 (Part 10) and triaxial shear strength tests per ASTM D4767 (Consolidated Undrained) / ASTM D2850 (Unconsolidated Undrained) and IS 2720 (Parts 11–13), on soil specimens where a low-capacity, precisely controlled loading rate is required rather than a high-capacity concrete/aggregate compression machine.
Related Products & Category
This machine is part of the Soil Testing Equipment range at Tvet Equipments. Related machines include: Laboratory Vane Apparatus, Pocket Penetrometer (Soil).
Frequently Asked Questions
What tests is the Universal Loading Frame designed for?
It is designed for low-capacity uniaxial and unconfined compression tests, including unconfined compression and triaxial testing of soil specimens.
Why is a wide, very fine speed range important?
A speed range down to 0.0001 mm/min allows the precise, slow strain rates required by consolidated and unconsolidated triaxial test procedures, alongside faster rates for standard unconfined compression tests.
Which standards does this frame support?
It supports unconfined compression testing per ASTM D2166 / IS 2720 (Part 10) and triaxial shear strength testing per ASTM D4767, ASTM D2850 and IS 2720 (Parts 11-13).
