Rapid Chloride Permeability Tester Manufacturer,Supplier and Exporter in India
Product Code : TVT-CTE-10534
The Rapid Chloride Permeability Tester evaluates concrete's ability to resist chloride ion penetration using the electric flux method, with an automatic acquisition, measurement and control system and a friendly human-machine interface for accurate, repeatable results.
How It Works
A concrete specimen (cube or cylindrical test block) is mounted in the test cell, with one face exposed to a sodium chloride solution and the other to a sodium hydroxide solution; a 60V potential is applied across the specimen for 6 hours, and the total electrical charge passed (in coulombs) is measured, indicating the concrete's resistance to chloride ion penetration — the test can also be used to estimate the chloride diffusion coefficient, chloride migration coefficient, and bulk electrical conductivity of the concrete.
Technical Specifications
| Parameter | Specification |
|---|---|
| Measuring Channels | 6 test pieces |
| Applied Voltage | 60V ± 0.1V |
| Measuring Time | 6 hours |
| Current Measurement Range & Accuracy | 0 – 500mA ± 0.1 |
| Data Transfer | U-disk upload; data exportable to Excel |
| Device Dimension / Weight | 300(L) x 300(W) x 200(H) mm / 9 kg |
| Test Cell Set Dimension / Weight | 160(L) x 150(W) x 100(H) mm / 1.2 kg per set |
| Operation Voltage | 240V, 50/60Hz, 1Ph |
Applications
Used to assess the durability of concrete exposed to chloride-contaminated environments (marine, de-icing salt, or industrial exposure) per ASTM C1202 and AASHTO T277 (electrical indication of concrete's ability to resist chloride ion penetration), a standard durability qualification test alongside carbonation and permeability testing.
Related Products & Category
This machine is part of the Concrete Testing Equipments range at Tvet Equipments. Related machines include: Concrete Carbonation Test Chamber, Digimatic Concrete Impermeability Apparatus.
Frequently Asked Questions
What does the Rapid Chloride Permeability Test measure?
It measures the total electrical charge passed through a concrete specimen over 6 hours under a 60V potential, indicating the concrete\u2019s resistance to chloride ion penetration.
How many specimens can be tested at once?
Up to 6 test pieces per run, across 6 measuring channels.
Can this instrument also estimate other durability parameters?
Yes — in addition to the standard chloride ion penetration result, it can estimate the chloride diffusion coefficient, chloride migration coefficient, and bulk electrical conductivity of the concrete.
