Marshall Loading Frame 50kN Manufacturer,Supplier and Exporter in India
Product Code : TVT-STE-10549
The Marshall Loading Frame 50kN is a dual-purpose bench-mounting loading frame combining California Bearing Ratio (CBR) penetration testing and Marshall stability testing in a single, rigid, DC-motorised machine, supplied without accessories so the correct penetration or breaking-head attachment can be ordered for the intended test.
How It Works
Depending on the accessory fitted, the machine drives either a CBR penetration piston at 1.2mm/min into a compacted soil specimen, or a Marshall breaking head at 50.8mm/min against a compacted bituminous specimen, with load and displacement/penetration recorded throughout. The DC power motor design reduces vibration and noise during operation, and the compact bench-mounting frame suits laboratories running both soil and bituminous mix testing.
Technical Specifications
| Parameter | Specification |
|---|---|
| Capacity | 50 kN |
| CBR Testing Speed | 1.2 mm/min |
| Marshall Testing Speed | 50.8 mm/min |
| Plunger Travel | 100 mm |
| Vertical Clearance | 680 mm |
| Horizontal Clearance | 270 mm |
| Product Dimension | 840(L) x 455(W) x 1310(H) mm |
| Packing Dimension | 1000(L) x 560(W) x 1500(H) mm |
| Approx. Product Weight | 185 kg |
| Approx. Packing Weight | 205 kg |
| Power | 220V, 2.5A, 50/60Hz, 1Ph, 370W |
Applications
Used for California Bearing Ratio testing of soil per ASTM D1883/IS 2720 Part 16 and Marshall stability/flow testing of bituminous mixes per ASTM D6926/D6927, letting a laboratory run both test types on a single loading frame by swapping the separately-ordered penetration or breaking-head accessory.
Related Products & Category
This machine is part of the Soil Testing Equipment range at Tvet Equipments. Related machines include: Advance CBR Loading Tester 50kN, Soil Testing Equipment.
Frequently Asked Questions
Can this frame run both CBR and Marshall tests?
Yes — its two published testing speeds (1.2mm/min for CBR, 50.8mm/min for Marshall) match both standards, but the correct penetration piston or Marshall breaking head accessory must be ordered separately for each test type.
What accessories come with the machine?
It is supplied without accessories; the CBR penetration piston and/or Marshall breaking head needed for your intended test must be ordered separately.
What is the maximum test capacity?
50kN.
