Automatic Touch Screen Compression Machine 3000kN Manufacturer,Supplier and Exporter in India
Product Code : TVT-CTE-10447
The Automatic Touch Screen Compression Machine 3000kN is the higher-capacity 3000 kN sibling of Tvet Equipments' touch-screen compression range, running the same Super Test software family with an imported DC motor drive for compression and flexural testing of concrete specimens.
How It Works
As with the 2000 kN touch-screen model, the Super Test software lets the operator enter test number, target strength, specimen age, sample size (cube, block or cylinder) and loading speed, displays the load-vs-time curve in real time, supports up to 10 samples per report, and allows manual entry of project and customer information into the printed report. Automatic or manual calibration with auto-correction for load error keeps readings consistent over time. The larger 300 mm piston ram diameter and 80 mm travel give this model its higher 3000 kN capacity compared with the 2000 kN version.
Technical Specifications
| Parameter | Specification |
|---|---|
| Max. Vertical Clearance | 378 mm |
| Max. Horizontal Clearance | 320 mm |
| Capacity | 3000 kN |
| Compression Platen Diameter | 295 mm |
| Piston Ram Diameter | 300 mm |
| Piston Ram Travel | 80 mm |
| Column Diameter | Ø78 mm |
| Accuracy Class | Class 1 |
| Relative Error | ±1% |
| Repeatability Relative Error | 1% |
| Resolution | 0.1 - 0.001 kN |
| Sensor Accuracy | 0.1% |
| Max. Hydraulic Working Pressure | 50 MPa |
| Product Dimension | 1030 x 520 x 1400 mm |
| Packing Dimension | 1130 x 620 x 1500 mm |
| Approx. Product Weight | 1100 kg |
| Approx. Packing Weight | 1150 kg |
| Power | 0.75 kW, 220V, 50/60 Hz, 1 Ph, 6 Amp |
Applications
Used for compressive strength testing of high-strength concrete cubes and cylinders per ASTM C39, IS 516, and EN 12390-4, and, with a flexural bend-test jig fitted, for flexural strength testing per ASTM C78 / C293, IS 516, and EN 12390-5 using the software's dedicated flexural program.
Related Products & Category
This machine is part of the Concrete Testing Equipments range at Tvet Equipments. Related machines include: Touch Screen Machine 2000kN, Welded Frame Compression Machine 3000kN.
Frequently Asked Questions
How does this differ from the 2000kN touch screen machine?
This model has a larger 300mm piston ram and higher 3000 kN capacity, versus the 250mm ram and 2000 kN capacity of the touch screen 2000kN model — otherwise both run the same Super Test software family.
What load resolution does the machine offer?
Resolution of 0.1-0.001 kN with 0.1% sensor accuracy and Class 1 accuracy overall.
Can it be used for flexural as well as compression testing?
Yes, using the software’s flexural test program together with a flexural bend-test jig accessory, per ASTM C293/EN 12390-5.
