Auto CBR Tester Manufacturer,Supplier and Exporter in India
Product Code : TVT-STE-10547
The Auto CBR Tester is a touch-screen-controlled California Bearing Ratio loading machine with a rigid, compact bench-mounting design and a servo-drive system, delivering reliable, highly accurate test results with real-time graphing.
How It Works
A compacted soil specimen in its CBR mould is loaded onto the machine's platen; a servo motor advances the penetration piston at a controlled rate while the large touchscreen displays a real-time load-penetration graph and captures test data automatically. An emergency stop button is provided for operator safety, and the servo drive reduces vibration and noise compared with conventional motor drives.
Technical Specifications
| Parameter | Specification |
|---|---|
| Capacity | 50 kN |
| Vertical Clearance | 690 mm max |
| Horizontal Clearance | 270 mm |
| Product Dimension | 565(L) x 505(W) x 1110(H) mm |
| Approx. Product Weight | 93 kg |
| Power Supplied | 220V, 50/60Hz, 0.5Hp, 370W, 0.45A |
Applications
Used to determine the California Bearing Ratio of compacted soil and pavement subgrade/subbase materials per ASTM D1883 and IS 2720 Part 16, with a touchscreen interface and real-time graphing suited to laboratories wanting automated data capture and reporting.
Related Products & Category
This machine is part of the Soil Testing Equipment range at Tvet Equipments. Related machines include: Advance CBR Loading Tester 50kN, Automatic Proctor / CBR Soil Compactor.
Frequently Asked Questions
What makes this an "Auto" CBR Tester?
A servo-drive system with a touchscreen controller automatically displays a real-time load-penetration graph and captures test data during the test, reducing manual data logging.
What safety features does this machine have?
An emergency stop button, alongside a servo drive that reduces vibration and noise during operation.
How does this differ from the Advance CBR Loading Tester 50kN?
This model uses a servo-drive system with touchscreen graphing and a slightly smaller 690mm vertical clearance and 93kg weight; the Advance CBR Loading Tester 50kN uses a DC motorised drive without touchscreen graphing, at 730mm clearance and 85kg.
