100kN Digimatic Load Cell Manufacturer,Supplier and Exporter in India
Product Code : TVT-CTE-10511
The 100kN Digimatic Load Cell is the lowest-capacity model in Tvet Equipments' load cell range, used for load and force verification/calibration of lower-capacity compression and flexural testing machines.
How It Works
As load is applied through the testing machine under calibration, strain in the sensitive steel-block element is transmitted to an amplifier, which converts it into a digital load reading. Comparing this reading against the testing machine's own indicated load verifies the machine's force accuracy across its working range.
Technical Specifications
| Parameter | Specification |
|---|---|
| Capacity | 100 x 0.01 kN |
| Load Cell Dimension | Ø60 x 178(H) mm |
| Working Temp. (as published) | 28.4 – 31.3°C, Moisture 68-72% RH |
| Accuracy | Class ±1% |
| Approx. Weight | 3.2 kg |
| Power | NiCd battery, AC adaptor as charging source |
Data note: the "Working Temp." field for this model gives a narrow, specific range (28.4-31.3°C, 68-72% RH), unlike the broader "0-45°C, Moisture ?80% RH" operating-range figure published for the 300kN, 2000kN and 5000kN models in this range — this reads more like a recorded test/calibration-room condition than a stated operating range. Presented as published; confirm the actual operating temperature/humidity limits with Tvet Equipments if this matters for your site conditions.
Applications
Used for load and force verification/calibration of compression testing machines per ASTM E4 (Standard Practices for Force Verification of Testing Machines) and ISO 376 (calibration of force-proving instruments), sized for lower-capacity laboratory machines.
Related Products & Category
This machine is part of the Concrete Testing Equipments range at Tvet Equipments. Related machines include: Digimatic Load Cell 300kN, Digimatic Load Cell 2000kN.
Frequently Asked Questions
What capacity machines is this load cell suited to?
At 100kN capacity, it is intended for calibrating lower-capacity compression or flexural testing machines, complementing the higher-capacity 300kN, 2000kN and 5000kN models in the range.
What is the accuracy class?
Class ±1%, the same accuracy class published across all models in this load cell range.
What does the published Working Temp. figure mean?
It reads as a narrow, specific temperature/humidity condition (28.4-31.3°C, 68-72% RH) rather than a broad operating range like the other models — likely a recorded test condition. Confirm actual operating limits with Tvet Equipments if needed.
