Cube Mold with Cast Iron Manufacturer,Supplier and Exporter in India
Product Code : TVT-CTE-10477
Cube Mold with Cast Iron is a cast-iron concrete cube mould, available in 100mm and 150mm sizes, from Tvet Equipments' wider range of cube, cylinder, and beam moulds offered in ABS plastic, high-density plastic, cast iron, and mild steel.
How It Works
Fresh concrete is placed and compacted (by tamping or vibration) into the assembled cast-iron mould to cast a cube specimen of precise, repeatable dimensions, then cured and demoulded once it has set sufficiently to retain its shape without damage to its edges or faces.
Technical Specifications
| Parameter | Specification |
|---|---|
| 100mm Cast Iron Cube Mould | 230 x 165 x 110 mm, 8.0 kg |
| 150mm Cast Iron Cube Mould | 285 x 215 x 160 mm, 15.6 kg |
| Note | This product listing\u2019s specifications are identical to Tvet Equipments\u2019 separately listed "Cast Iron Cube Mould (L-Shape)" product — it appears this may be a duplicate catalog entry for the same item rather than a distinct mould design. Please confirm with Tvet Equipments whether this differs from the L-Shape listing before ordering. |
Applications
Used to cast standard 100mm and 150mm concrete cube specimens for compressive strength testing per ASTM C31, IS 516, and EN 12390-1, which specify cube mould dimensional tolerances for compression testing.
Related Products & Category
This machine is part of the Concrete Testing Equipments range at Tvet Equipments. Related machines include: Cast Iron Cube Mould (L-Shape), Mild Steel Cube Moulds.
Frequently Asked Questions
How is this different from the Cast Iron Cube Mould (L-Shape) product?
Based on the published specifications, this listing carries identical dimensions and weights to the L-Shape cube mould product — it appears to be a duplicate catalog entry rather than a distinct design; confirm with Tvet Equipments if a genuine difference exists.
What sizes are available?
100mm and 150mm standard cube sizes, the two sizes specified in ASTM C31/IS 516 for concrete cube compression testing.
Why choose cast iron over plastic cube moulds?
Cast iron gives a heavier, more rigid, longer-lasting mould that resists distortion under repeated site or lab use better than lighter plastic moulds, though plastic moulds are lighter to handle.
