Automatic Mortar Compression - Flexural & Concrete Flexural Machine 300kN Manufacturer,Supplier and Exporter in India
Product Code : TVT-CMTE-10424
The Automatic Mortar Compression - Flexural & Concrete Flexural Machine 300kN from Tvet Equipments is a dual-range, industrial-computer-controlled machine that performs both mortar compression testing and concrete beam flexural testing on a single touch-screen platform running Testmaster Software V7.2.
How It Works
The specimen — a mortar cube fitted with the supplied compression jig, or a concrete beam fitted with the supplied flexural device — is loaded between the machine's 160 mm diameter top and bottom platens. The built-in industrial computer, operated via touch screen, controls the loading rate across a 0.1-10 kN/s range and records force with 0.01 kN resolution at Class 1 (1%) accuracy, with a loading rate error within ±1%, giving laboratories one automated machine capable of running two distinct test types.
Technical Specifications
| Parameter | Specification |
|---|---|
| Capacity | 300 kN |
| Speed Control Range | 0.1-10 kN/s |
| Resolution | 0.01 kN |
| Platen Diameter | Ø160 mm, top & bottom |
| Measuring Range | 0.2-100% F.S. |
| Accuracy | 1% (Class 1) |
| Loading Rate Error | ±1% |
| Main Frame Dimension (L x W x H) | 850 x 510 x 1335 mm |
| Approx. Weight | 293 kg |
| Power | 220 V, 50/60 Hz, 1 ph, 1 Hp, 750 W, 5 A |
Applications
This machine performs mortar compressive strength testing to ASTM C109 / EN 196-1 / IS 4031 Part 6 and concrete beam flexural strength testing to ASTM C78 / ASTM C293 / IS 516, combining both test types on one automated platform for laboratories running both mortar and concrete quality control.
Related Products & Category
Part of Tvet Equipments' Cement & Mortar Testing Equipments range, complementing the 50mm Mortar Cube Compression Device jig.
Frequently Asked Questions
Q1. Can this machine test both mortar and concrete specimens?
Yes, it is supplied with a compression jig for mortar cube testing and a concrete beam flexural device, letting it perform both mortar compression testing and concrete flexural testing.
Q2. What standards does it test to?
ASTM C109 / EN 196-1 / IS 4031 Part 6 for mortar compression, and ASTM C78 / ASTM C293 / IS 516 for concrete flexural strength.
Q3. How is the machine controlled?
Through a built-in industrial computer with touch-screen operation running Testmaster Software V7.2, controlling loading rate and recording results automatically.
