Mortar Prism Flexural Device Manufacturer,Supplier and Exporter in India
Product Code : TVT-CMTE-10425
The Mortar Prism Flexural Device from Tvet Equipments is a steel three-point bending jig used to carry out flexural testing on 40.1 x 40 x 160 mm mortar prism specimens within a compatible compression/flexural testing machine.
How It Works
The mortar prism specimen rests on two lower steel bearers set at a fixed 100 mm span. An upper longitudinal bearer, fitted to a self-aligning ball setting, applies the load at the mid-span of the specimen as the testing machine's ram advances, ensuring even load distribution across the prism's width even if the specimen or bearers are not perfectly aligned. The specimen is loaded to failure, and the recorded peak load is used to calculate flexural strength.
Technical Specifications
| Parameter | Specification |
|---|---|
| Specimen Size | 40.1 x 40 x 160 mm |
| Bearer Span | 100 mm |
| Dimension (L x W x H) | 160 x 88 x 169 mm |
| Approx. Weight | 5.6 kg |
Applications
This device is used to carry out flexural strength testing of 40 x 40 x 160 mm cement mortar prisms to EN 196-1 and IS 4031 Part 6, providing the standard-specified 100 mm three-point bending span within a compatible testing machine.
Related Products & Category
Part of Tvet Equipments' Cement & Mortar Testing Equipments range, used together with the 40.1 x 40 x 160mm Mortar Prism Compression Device for the subsequent compression test on the broken half-prisms.
Frequently Asked Questions
Q1. What standard governs this flexural test set-up?
EN 196-1 and IS 4031 Part 6 both specify the 100 mm span three-point bending method this device provides for testing 40 x 40 x 160 mm mortar prisms.
Q2. Why does the upper bearer have a self-aligning ball setting?
The self-aligning fitting ensures the load is distributed evenly across the specimen's width, even with minor misalignment, giving a more accurate flexural strength result.
Q3. What happens to the specimen after this test?
The two broken half-prisms from the flexural test are then typically tested in compression using a matching compression jig, following the standard's two-stage test sequence.
