Marshall Stability Compression 50kN Manufacturer,Supplier and Exporter in India

Marshall Stability Compression 50kN

Product Code : TVT-BATE-10335

The Marshall Stability Compression 50kN tester from Tvet Equipments is a newly redesigned, rigid, bench-mounting machine for measuring the stability and flow of Marshall asphalt specimens.

How It Works

A DC motorised drive system applies compressive load to the specimen through a breaking head at a controlled testing speed; load and specimen deformation (flow) are recorded to determine the Marshall stability value, with the compact bench-mount design giving more reliable, repeatable results than earlier models.

Technical Specifications

ParameterSpecification
Capacity50 kN
Testing Speed50.8 mm/min
Plunger Travel60 mm
Vertical Clearance730 mm
Horizontal Clearance270 mm
Product Dimension525(L) x 445(W) x 1150(H) mm
Approx. Product Weight98 kg
Power220V, 2.5A, 50/60Hz

Applications

Marshall stability and flow testing follows ASTM D6927, the standard mix-design and quality-control test for hot-mix asphalt used on Indian highway projects.

Related Products & Category

Part of Tvet Equipments' Bitumen Asphalt Testing Equipment range, used together with the Marshall Water Bath and Manual Marshall Compactor.

Frequently Asked Questions

Q1. What does the Marshall Stability test measure?
The stability (peak load) and flow (deformation) of a compacted asphalt specimen.

Q2. What is the machine's load capacity?
50 kN.

Q3. Which standard applies?
ASTM D6927.

Request a Quote

Contact Tvet Equipments for pricing, lead time, and export documentation. Request a Quote
