Hand Operated Vertical Universal Extruder Manufacturer,Supplier and Exporter in India
Product Code : TVT-STE-10592
The Hand Operated Vertical Universal Extruder is a free-standing, hand-pump-operated hydraulic extruder capable of extruding soil specimens from 38 mm up to 152 mm in diameter, covering the full range of common Proctor, CBR and undisturbed sample tube sizes.
How It Works
A hand pump drives a hydraulic jack with a total ram stroke of up to 500 mm and a maximum extruding force of 8 tons, advancing the ram smoothly through the mould or tube to push the specimen out with minimal disturbance. The extruder head carries an external thread so that the full range of adaptors — ordered separately to suit the specific mould or tube diameter — can be fitted, giving one base unit the flexibility to handle 38 mm to 152 mm diameter specimens.
Technical Specifications
| Parameter | Specification |
|---|---|
| Extruding Diameter Range | 38 mm to 152 mm (via separately ordered adaptors) |
| Maximum Force | 8 tons |
| Ram Diameter | 30 mm |
| Max. Ram Stroke | 500 mm |
| Dimension | 600 (L) x 390 (W) x 720 (H) mm |
| Approx. Weight | 29 kg |
| Accessories | Extruder adaptor kits ordered separately to suit mould/tube diameter |
Applications
This extruder supports specimen removal across the full range of Proctor/CBR compaction moulds (ASTM D698/D1557/D1883, IS 2720 Parts 7, 8 & 16) and undisturbed thin-walled sample tubes (ASTM D1587), giving laboratories a single hand-operated unit to cover their full mould and tube inventory rather than dedicated extruders for each diameter.
Related Products & Category
This machine is part of the Soil Testing Equipment range at Tvet Equipments. Related machines include: Universal Extruder 38 kg, Sample Tube Extruder 38mm Diameter.
Frequently Asked Questions
What diameter range does this extruder cover?
With the appropriate adaptor, it covers 38 mm to 152 mm diameter specimens, spanning common CBR/Proctor moulds and undisturbed sample tubes.
Are the adaptors included?
No, extruder adaptor kits for specific mould/tube diameters must be ordered separately to suit the sizes in use.
How is the extruder operated?
It is operated by hand pump, driving a hydraulic jack with up to 8 tons of extruding force and a 500 mm ram stroke.
