Autoclave Manufacturer,Supplier and Exporter in India
Product Code : TVT-CMTE-10415
The Autoclave from Tvet Equipments is a high-pressure steam vessel built from special alloy steel, used to determine the autoclave expansion (soundness) of Portland cement specimens under controlled high-pressure, high-temperature steam conditions.
How It Works
Cured cement paste bar specimens (cast in a two-gang or similar prism mould with embedded gauge studs) are loaded into the autoclave's 158 mm diameter, 460 mm deep internal chamber, which holds up to 9 specimens per run. The vessel is sealed and steam pressure is raised to a controlled maximum of 2.2 MPa via the system control compartment and pressure regulator, subjecting the specimens to accelerated hydration conditions. After the prescribed autoclave cycle, specimens are cooled and re-measured for length change to determine the percentage expansion.
Technical Specifications
| Parameter | Specification |
|---|---|
| Internal Dimension | 158 mm dia. x 460 mm depth |
| Maximum Pressure | 2.2 MPa |
| Number of Specimens | 9 nos. |
| Cell Dimension | 550 mm dia. x 1120 mm (H) |
| Control Unit Dimension | 450 x 300 x 800 mm |
| Approx. Weight | 120 kg |
| Power | 220 V, 1 ph, 50/60 Hz, 1.2 kW |
Applications
This autoclave is used to determine the autoclave expansion of Portland cement to ASTM C151 / IS 4031 Part 3, the standard method for detecting unsoundness caused by excess free lime or magnesia content in cement.
Related Products & Category
Part of Tvet Equipments' Cement & Mortar Testing Equipments range, used together with the Two Gang Prism Mould used to cast the test bars.
Frequently Asked Questions
Q1. What standard governs autoclave expansion testing?
ASTM C151 and IS 4031 Part 3 specify the autoclave expansion method for detecting unsoundness in Portland cement.
Q2. How many specimens can be tested per run?
The autoclave's internal chamber accommodates up to 9 specimens per test run.
Q3. What pressure does the autoclave operate at?
It operates up to a maximum pressure of 2.2 MPa, controlled via the pressure regulator and system control compartment.
