Fully Automatic Universal Testing Machine 100kN Manufacturer,Supplier and Exporter in India
Product Code : TVT-STE-10612
The Fully Automatic Universal Testing Machine (100 kN) is a twin-column, electromechanical tensile and compression testing system driven by a DC speed-regulating servomotor and precision ball screws, suited to a wide range of metal, non-metal and composite materials.
How It Works
A servo drive and servo motor advance the crosshead via twin high-precision ball screws along twin rigid columns, with test speed held under closed-loop control and single-chip automatic control managing the professional servo system's PWM (pulse-width-modulation) drive. Test data and status are displayed in real time on an LCD module, with selectable curve axes (time, load, displacement, deformation, stress or strain) and key results — maximum force, tensile strength, upper and lower yield — captured automatically via the Test Master software, with a computer connector for data export. Safety features include emergency stop, overload protection, and upper/lower limit switch sensors with automatic retreat.
Technical Specifications
| Parameter | Specification |
|---|---|
| Force Capacity | 100 kN |
| Structure Type | Twin rigid column with twin high-precision ball screw |
| Vertical Space | 600 mm |
| Horizontal Space | 450 mm |
| Accuracy Class | Class 1 (±0.5%) |
| Test Speed Range | 0.01–500 mm/min |
| Load Resolution | 1/100,000 |
| Measuring Range | 1–100% F.S. |
| Load Units | MN, N, t and kN (selectable) |
| Main Drive Unit | Servo drive and servo motor |
| Software | Test Master |
| Safety Features | Emergency stop, overload protection, upper/lower limit switch sensors with auto-retreat |
| Power Source | AC 220 V, single phase, 50/60 Hz |
| Dimension | 910 (L) x 480 (W) x 2000 (H) mm |
| Approx. Weight | 500 kg |
Applications
This machine is used for the mechanical property measurement and analytical study of metal, non-metal and composite materials across industries including aviation, petrochemical, machinery manufacture, wire and cable, textile and fibre, plastic, rubber, ceramic, and construction materials. For steel and metallic products, it supports tensile and compression testing per ASTM E8/E8M, ASTM A370, ISO 6892-1 and IS 1608, with its electromechanical ball-screw drive suiting laboratories that want fully automatic, computer-controlled testing at a lower capacity than the electro-hydraulic 300 kN and 1000 kN machines in the range.
Related Products & Category
This machine is part of the Steel Testing Equipments range at Tvet Equipments. Related machines include: Electro-Hydraulic Servo Control Universal Testing Machine 1000kN, Electro-Hydraulic Servo Control Universal Testing Machine 300kN.
Frequently Asked Questions
How does this machine differ from the electro-hydraulic servo models?
This 100 kN machine uses a twin-column, ball-screw electromechanical drive system rather than electro-hydraulic servo control, suiting lower-capacity, fully automatic testing of a wide range of materials.
What materials can this machine test?
It is designed for mechanical property testing of metal, non-metal and composite materials across industries such as aviation, petrochemical, textile, plastic, rubber and construction materials.
What load units are available?
Results can be displayed in MN, N, tonnes or kN, selectable to suit the user\u2019s reporting requirements.
