Laboratory Coring Machine Manufacturer,Supplier and Exporter in India

Laboratory Coring Machine

Product Code : TVT-ARTE-10295

The Laboratory Coring Machine from Tvet Equipments is a portable unit used to extract cylindrical cores from irregular rock samples, preparing specimens for point load, UCS, and other strength tests.

How It Works

A rotating diamond core bit, driven by the machine's motor, cuts into the rock sample while a water-filled tank flushes cuttings and cools the bit; the stroke-length feed advances the bit through the sample to produce a clean cylindrical core of consistent diameter.

Technical Specifications

ParameterSpecification
Tank Dimension800(L) x 700(W) x 540(H) mm
Maximum CoringØ 130 mm
Stroke Length400 mm
Speed750 r.p.m.
Approx. Weight70 kg
Power240V, 1ph, 50/60Hz, 1000W

Applications

Rock coring for laboratory specimen preparation follows ASTM D2113 practice, supplying test-ready cylindrical cores for strength and point-load testing in tunnel, dam, and quarry investigation programs across India.

Related Products & Category

Part of Tvet Equipments' Aggregate & Rock Testing Equipments range, used to prepare specimens for the Digimatic Point Load Tester Apparatus.

Frequently Asked Questions

Q1. What is the Laboratory Coring Machine used for?
It extracts cylindrical cores from irregular rock samples for further strength testing.

Q2. What is the maximum coring diameter?
Up to Ø 130 mm.

Q3. Which standard covers rock coring practice?
ASTM D2113.

Request a Quote

Contact Tvet Equipments for pricing, lead time, and export documentation. Request a Quote
