Aggregate Shape Gauge

Product Code : TVT-ARTE-10327

The Aggregate Shape Gauge from Tvet Equipments measures the shape factor of aggregate particles, a quick hand-held check used alongside sieve-based elongation and flakiness testing.

How It Works

Individual aggregate particles are placed against the gauge's calibrated slots; a particle that passes through a given slot is classified accordingly, and the pass/fail pattern across the sample is used to compute the aggregate's shape factor.

Technical Specifications

ParameterSpecification
Dimension160(L) x 320(W) mm
Approx. Weight500 g
Tolerance/Limit (L/E)± 0.05
Scale Sensitivity0.05 mm

Applications

Shape-factor and elongation/flakiness assessment of aggregate is carried out as per IS 2386 (Part I), supporting particle-shape acceptance checks for road and concrete aggregate across India.

Related Products & Category

Part of Tvet Equipments' Aggregate & Rock Testing Equipments range, used alongside the Grid Sieves Set.

Frequently Asked Questions

Q1. What does the Aggregate Shape Gauge measure?
It measures the shape factor of aggregate particles.

Q2. What is the scale sensitivity?
0.05 mm, with a tolerance/limit of ±0.05.

Q3. Which standard applies?
IS 2386 (Part I).
