Digimatic Point Load Tester Apparatus Manufacturer,Supplier and Exporter in India
Product Code : TVT-ARTE-10284
The Digimatic Point Load Tester Apparatus from Tvet Equipments determines the point load strength index of rock and aggregate specimens, both in the field and in the laboratory, giving civil engineering colleges, highway testing labs, and PWD/NHAI-empanelled laboratories a fast, portable way to estimate rock strength and correlate it to Uniaxial Compressive Strength (UCS).
How It Works
A rigid load frame with a hydraulic loading ram, actuated by hand pump, applies load through conical platens onto the rock specimen. A digital load cell with fine-resolution reading control records the applied load, while the built-in ruler allows direct measurement of specimen diameter for accurate index calculation. The rechargeable digital readout can store up to 999 test results for lab record-keeping.
Technical Specifications
| Parameter | Specification |
|---|---|
| Power | 1.8 Ah Rechargeable with AC 220V |
| Result Storage | 999 Test Results |
| Max. Capacity | 50 kN x 0.01 kN Sensitivity |
| Max. Specimen Test | 110 mm Dia. |
| Accuracy & Repeatability | ≤1.0% F.S |
| Approx. Weight | 40 kg |
| Case Dimension (mm) | 280(L) x 220(W) x 680(H) mm |
Applications
Point load testing is a rapid, low-cost index test widely used as per IS 8764:1998 and ASTM D5731 to estimate rock strength for tunnel, highway, dam foundation, and quarry investigation work, and is a standard requirement in geotechnical site investigation reports submitted to PWD and NHAI-affiliated projects across India.
Related Products & Category
The Digimatic Point Load Tester Apparatus is part of Tvet Equipments' Aggregate & Rock Testing Equipments range, alongside the Aggregate Impact Value Apparatus and Sand Equivalent Test Apparatus.
Frequently Asked Questions
Q1. What does a Point Load Tester measure?
It measures the point load strength index of rock or aggregate specimens, which is used to estimate compressive strength and overall rock quality.
Q2. Which standard governs point load index testing?
Point load testing on this apparatus is carried out as per IS 8764:1998 and ASTM D5731.
Q3. Can this apparatus be used for both field and laboratory testing?
Yes, its portable hand-pump-actuated design allows use for both on-site field testing and controlled laboratory testing.
