Data Logger Rain Gauge Manufacturer,Supplier and Exporter in India
Product Code : TVT-MTE-10697
The Data Logger Rain Gauge is a battery-powered tipping-bucket rain gauge system with an event data logger, used to automatically record rainfall amount, timing, and duration.
How It Works
A tipping-bucket mechanism registers a discrete "tip" each time a fixed, calibrated volume of rain has been collected; a Pendant Event data logger records a time and date stamp for every tip, allowing rainfall rate and duration to be reconstructed afterward, with data retrieved via a base station or shuttle. When fitted with an optional solar radiation shield, the system can also record temperature. The system can record up to 160 inches of accumulated rainfall, at rates up to 12.7cm (5 inches) per hour.
Technical Specifications
| Parameter | Specification |
|---|---|
| Max. Rainfall Range | 12.7 cm (5 in) per hour |
| Calibration Accuracy | ±1.0% |
| Approx. Weight | 1.2 kg |
| Data Retrieval | Base station or shuttle required |
Applications
Data logger rain gauges are used for automated, unattended rainfall monitoring at hydrological and meteorological stations, recording precise timing and duration data needed to analyse rainfall intensity and patterns, offering a field-proven, reliable alternative to manual gauge reading.
Related Products & Category
This machine is part of the Miscellaneous Testing Equipments range at Tvet Equipments. Related machines include: Copper Rain Gauge, Plastic Rain Gauge.
Frequently Asked Questions
How does the tipping-bucket mechanism work?
It registers a discrete "tip" each time a fixed, calibrated volume of rain has been collected, with each tip time-and-date stamped by the data logger.
Is a base station required?
Yes, a base station or shuttle is required to retrieve the logged rainfall, time, and duration data.
Can it also record temperature?
Yes, when fitted with an optional solar radiation shield, the system can also record temperature.
