Large Sample Splitter

Product Code : TVT-ARTE-10321

The Large Sample Splitter (fully enclosed version) from Tvet Equipments is built for fine, dusty powders, or samples where moisture retention matters during splitting.

How It Works

A transparent compartment on top of the feeding chutes lets the operator monitor the sample while it is fully enclosed during splitting; chute bars 1/2" wide with opening sizes from 1/2" to 4" divide material up to 108 mm into two representative portions, with cadmium-coated construction for rust protection.

Technical Specifications

ParameterSpecification
Max. Material SizeUp to 108 mm
Chute Bar Width1/2"
Opening Sizes1/2", 1", 1 1/2", 2", 3", 4"
Dimension545(L) x 370(W) x 620(H) mm
Approx. Weight183 kg

Applications

Fully enclosed sample splitting suits fine or dusty aggregate and soil samples where dust containment or moisture retention is important, following ASTM C702 sample-reduction principles.

Related Products & Category

Part of Tvet Equipments' Aggregate & Rock Testing Equipments range, an enclosed alternative to the Large Sample Splitter (60kg).

Frequently Asked Questions

Q1. Why choose the fully enclosed version?
It contains fine, dusty powders and helps retain sample moisture during splitting.

Q2. What is the maximum material size?
Up to 108 mm.

Q3. How much does it weigh?
Approximately 183 kg.
